توضیحات
- 8 mono mic/line inputs with gain control, one-knob compressor, 75Hz highpass filter, 4-band semiparametric EQ, 4 AUX busses, pan control and peak LED
- 2 mono Mic/stereo Line inputs with gain control, 4-band shelving EQ, balance control and peak LED
- 2 stereo Line inputs with gain control, 4-band shelving EQ, balance control and peak LED
- 5mm TRS stereo inputs in 2 stereo channels
- 60mm faders for level control in all channels
- All mic channels with insert jack
- Channels assignable to Master (LR) or subgroup pair 1+2 or subgroup pair 3+4
- 4 Subgroups with external outputs, assignable to Master L or R, 60mm fader per subgroup
- Switchable +48V phantom power for microphone inputs
- Two AUX busses fixed post-fader (one assigned to internal effects), two AUX busses switchable pre/post
- Post-fader AUX returns re-routable to Monitor AUX send
- TriCore DSP 24-Bit stereo effects processor with LCD display, external output and footswitch control. 15 algorithms in 6 groups, editable in up to 3 parameters per algorithm. Tap tempo function.
- Tape record/playback with flexible routing
- USB stereo soundcard for replay and recording
- Control Room/headphones output with selectable source
- Master with 60mm fader and 2×15 LED meter
- SOLO for channels and AUX send, PFL/AFL
- Internal switch mode power supply
- Full metal case with detachable plastic side panels and mountable metal rack ears (included)
- CE/ROHS compliant
میکسر آنالوگ 14 10 4 2 1 اکولایزر پارامتریک- 3 باندی- مید سوییپر 4 USB
